CONFORMITY
- Large warning labels in compliance with ISO 3864 norm, and
92/58/CEE european directive.
ADVANTAGES
- Especially designed for acids and bases storage
- Built in high density polyethylene (HDPE) with a high resistance
to vapours and corrosive liquids.
- Independent storage compartments for acid and base.
PASSIVE SECURITY
- Entirely built in light grey high density polyethylene (HDPE).
- Acids”and ”Bases" warning labels.
- Removable retention tank in PVC (at each level; retention
capacity 6 I per tank).
- Equipped with shelves for acid and base separate storage (exept
model RB1).
OPTIONS
- 4 swivel castors for RB1 and RB2 models (60 mm of extra
height).
- Opening vent with connection unit Q 100 mm (must be ordered
with the cabinet)
ACTIVE SECURITY
- Front opening with retractable door.
- Door(s) with lock (for each level).
Ventilation and Filtration
Boxes
To protect the users health and to
improve the life cycle of your
safety cabinet, we recommend to
install an exhausting system. Do
not hesitate to contact us for more
information.
Rb1
RB1VENT
Rb2
RBZVENT
Rb3
RBSVENT
Rb4
RB4VENT
RBROU
Safety Cabinets with 1 compartment
Opening vent for RB1 (must be ordered with the cabinet)
Safety Cabinets with 2 compartment
Opening vent for RB2 (must be ordered with the cabinet)
Safety Cabinets with 3 compartment
Opening vent for RB3 (must be ordered with the cabinet)
Safety Cabinets with 4 compartment
Opening vent for RB4 (must be ordered with the cabinet)
4 swivel castors for RB1 or RB2
480 x 950 x 410
900 x 950 x 410
1320 x 950 x 410
1740 x 950 x 410
330 x 850 x 360
(2x) 330 x 850 x 360
(3x) 330 x 850 x 360
(4x) 330 x 850 x 360
35
70
105
140
Ref. Description
External dim.
H x W x D (mm)
Internal dim.
H x W x D (mm)
Weight
(kg)
15
-
30
-
45
-
60
-
0.5
Storage
capacity (L)
Corrosive Cabinets
RANGE 10
EN
EN
14470-1
1363-1
POLYETHYLENE SAFETY CABINETS
for Acids and Bases
Acids
Bases
Rb4
Rb1
Rb2
Rb3
216
