RANGE 7 .EN & 7030
EN
EN
14470-1
1363-1
EN 14470-1 SAFETY CABINETS - Type 30 minutes
for ammable products
Self-closing doors
with thermo-fuse
Perforated cover plate
for base trough
Pedestal area
under-driveable
by a forklift
Adjustable
levelling legs
Adjustable
shelf
Normalized
label
NORMS AND REGULATIONS
- Tested and approved according to EN 14470-1 (04/2004) and
EN 1363-1 (06/2000).
- Normalized labelling according to ISO 3864 and EN 14470-1
(04/2004) norms, and 92/58/CEE european directive.
ADVANTAGES
- Fire resistance during 30 minutes in accordance with ISO 834 re
heating curve.
- Pedestal area under-driveabIe by a forklift by removing panel.
PASSIVE SECURITY
- Built in H.P.L. (high pressure laminated) : high chemicals
resistance.
- Body and edges in grey colouring (RAL 7035) except for 7035
model, edges in yellow colouring (RAL 1023).
- Markings as per EN 14470-1.
- Earthing link.
- Retention shelves.
- Removable base trough at the bottom.
- Perforated cover plate for base trough (except for 7035 model in
option).
ACTIVE SECURITY
- Air inlet and outlet with 100 mm connecting pieces for possible
exhaust.
- Self-closing doors.
- Possibility to keep the doors open. If the temperature rises to
50°C, a fuse link closes the doors automatically.
- Doors with cylinder locks.
- Adjustable leveling legs.
OPTIONS
- Additional shelf.
- Perforated cover plate for base trough (model 7035).
APPROVED
30
min
ACCORDING TO
EN-14470-1
Flammable Cabinets
7035E
213
