RANGE 7.90
EN
EN
14470-1
1363-1
Flammable Cabinets
EN 14470-1 SAFETY CABINETS - Type 105 minutes
for ammable products
CONFORMITY
- Tested and approved according to EN 14470-1 (O4/2004) and
EN 1363-1 (O6/2000).
- Normalized labelling according to ISO 3864 and EN 14470-1
(O4/2004) norms, and 92/58/CEE european directive.
ADVANTAGES
- Fire resistance during 90 minutes (approved Type 90) in
accordance with ISO 834 re heating curve.
- Tested and approved by an independent European laboratory.
PASSIVE SECURITY
- Double wall construction.
- Outer housing made of sheet steel (12/10”‘) with high quality
Epoxy coating RAL 9010.
- Inner body built in grey (RAL 7035) H.P.L.-coated sheet (high
pressure laminated).
- Thermal insulation panel between the walls avoiding thermal
bridges.
- Removable base trough at the bottom, except for 792T,
integrated base trough.
- Markings as per EN 14470-1.
- Adjustable retention shelves.
- Earthing link.
ACTIVE SECURITY
- Air inlet and outlet channel in rear panel. Easy connection on the
roof of the cabinet ® 100 mm (labelled as exhaust channel).
- In case of re, a thermo-fuse automatically seals off the
ventilation system.
- Thermo-expanding seals of the door(s) allow keeping the internal
body reproof.
- Separately locking door(s) with cylinder locks
- Self-closing door(s) with possibility to keep the door(s) open. If
the temperature rises to 50°C, a fuse link closes the door(s)
automatically.
OPTIONS
- Doors with different color possibilities
• frame and shelves in white (RAL 9010); doors in yellow (RAL1023)
• frame and shelves in white (RAL 9010); doors in red (RAL 3000)
TESTED
105
min
ACCORDING TO
EN-14470-1
APPROVED
90
min
ACCORDING TO
EN-14470-1
Normalized
Label
Retention
Shelf
Vent with
Thermo-fuse
Self-closing door(s)
with thermo-fuse
Key locking
System
Removable base
Trough
795E + C79235
215
