TLC and HPTLC Plates Manufactured by Macherey-Nagel GmbH & Co., Germany
Nano silica layers for HPTLC
Packing Material
Packing Material
HPTLC- Glass plates, Layer thickness: 200 µm
HPTLC silica gel 60,Glass plates, Layer thickness: 200 µm
Prod. Code
Prod. Code
Price for Unit
`
Price for Unit
`
Plate size [cm]
Plate size [cm]
Pack of [plates]
Pack of [plates]
Nano-ADAMANT
Nano-SIL
2
• Nano silica 60, specific surface (BET) ~500m /g, mean pore size 60 Å, specific pore volume 0.75mL/g,
particle size 2 - 10 µm
•
Outstanding
hardness and
abrasion resistance
due to an optimized binder system
•
Increased separation efficiency
due to an optimized particle size distribution
•
High suitability for trace analyses
resulting froma UV indicator with increased brilliance and a low noise background
of the layer
• Narrow fractionation of the silica particles allows theoretical plate heights, which are one order of magnitude smaller than
on standard silica layers with the advantage of sharper separations, shorter developing times, shorter migration distances,
Lower amount of samples, and increased detection sensitivity with equal selectivity.
2
• Nano silica 60, specific surface (BET) ~500m /g, mean pore size 60 Å, specific pore volume 0.75mL/g,
particle size 2 - 10 µm
Indicator: manganese activated zinc silicate with green fluorescence for short-wave UV (254 nm)
Binder: highly polymeric product, which is stable in almost all organic solvents and resistant towards aggressive
visualization reagents
• Narrow fractionation of the silica particles allows sharper separations, shorter developing times, shorter migration
distances, smaller samples and an increased detection sensitivity compared to SIL Gplates.
®
• Available as glass plate and as ALUGRAM Xtra aluminiumsheet with or without fluorescent indicator
unmodified HPTLC silica layers
unmodified HPTLC silica layers
®
ALUGRAM Xtra aluminium sheets
®
ALUGRAM aluminium sheets
Nano-ADAMANT
821140
10 x 10
25
17990
821150
10 x 20
50
43350
Nano-ADAMANT, UV254
821110
10 x 10
25
17990
821120
10 x 20
50
44350
Nano-SIL -20
811011
5 x 5
100
25990
811012
10 x 10
25
17990
811013
10 x 20
50
42990
Nano-SIL 20, UV254
811021
5 x 5
100
25990
811022
10 x 10
25
17990
811023
10 x 20
50
48990
Nano-SIL - G
818240
5 x 20
50
18250
818241
20 x 20
25
28360
Nano-SIL G, UV254
818342
5 x 20
50
18250
818343
20 x 20
25
32250
Nano-SIL - G
818141
20 x 20
25
48990
Nano-SIL G, UV254
818143
20 x 20
25
49990
Analytical Chromatography
MN
28
